31
10. Installation is the reverse procedure. Carefully turn the new
Resistance Knob clockwise to install it through the Top Spacer, Spring
and Square Spacer inside the mount tube.
Note: Hold the Square Spacer and Spring so that the Spring
touches the Top Spacer inside the square mount, until the
Shaft is threaded through the Square Spacer.
11. Final Inspection
Inspect your machine to ensure that all hardware is tight and
components are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
Resistance Nut
9. Using a 10mm open end wrench and a 5mm hex wrench, remove
the hardware (indicated by arrows) from both sides of the machine.
