67
8. Using a 32mm Open Faced Wrench or an Adjustable Wrench,
remove the Threaded Cap from the Frame Assembly.
Note: If the Threaded Cap will not come loose, it may be set with
a thread lock compound. Using a Heat Gun, safely heat the
Threaded Cap until it can be removed.
Be sure to follow any manual or safety instructions supplied
from the manufacturer as regards to the proper and safe use
of the Heat Gun. Do not grasp any items or surfaces that have
been heated without the proper heat resistant materials.
9. Use the small standard screwdriver to remove the Wedge Bushing
exposed behind the Threaded Cap from the Frame Assembly, or safely tilt
the machine until the Wedge Bushing falls from the Frame Assembly.
Note: Be sure to notice how the Wedge Bushing engages within the engages within the
Frame Assembly to assist with re-assembly.Frame Assembly to assist with re-assembly.
Threaded
Cap
