Nautilus E618 Service Manual

106
5.Usinga6mmhexkey,loosenandremovetheindicatedhardwarefrom
the Crank Arm and Leg, and set it safely aside for reassembly. On each
side of the machine, remove the Leg and Pedal together from the Rail
Assembly and set them safely aside for reassembly.
NOTICE: This step may require two people.
9. Using a small standard screwdriver, gently pry the cap off of the Crank
Arm.
10. Using a 14mm socket and ratchet, remove the Lock Nut from the
Crank Arm.
Leg
Crank Arm

Nautilus E618 Specifications

General

Display	LCD
Programs	29
Heart Rate Monitoring	Contact and telemetry enabled
Bluetooth Connectivity	Yes
User Profiles	4
Maximum User Weight	300 lbs
