19. Installation is the reverse procedure.
Note: Be sure the number of threads showing on the Lift Motor shaft
between the Collar Nut and the Lift Motor base is the same as the
number recorded in Step 16. If the number is different, turn the
collar nut until the thread count is the same.
PuttheLeftShroudinpositionrsttoalignthescrewsfortheRightShroud.
Installthetopscrewsrst.BesurethetabsintheMotorizedLiftCoversnap
into the Side Shrouds.
NOTICE: This step may require two people. Be sure not to crimp any
cables.
Note: Self-tapping screws attach the Shrouds to the Frame.
Installation does not require the use of the crank puller. Be sure the Crank
Arms are connected at 180° from each other.
20. Dispose of the old parts.
21. Inspect your machine to ensure that all hardware is tight and components
are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
