Nautilus E618 Service Manual

90
!
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the
wall outlet and wait 5 minutes before cleaning, maintaining or repairing this machine. Place the power cord in a secure
location.
1. To remove the Console Junction Cover, pinch the sides to release the
side snaps, and then pivot it forward and off of the machine.
2.Usinga6mmhexwrench,removetheindicatedhardwarefromthe
Console Mast.
Console Junction
Cover
Console Junction
Cover
Static
Handlebar
Console
Console Mast

Nautilus E618 Specifications

General

Display	LCD
Programs	29
Heart Rate Monitoring	Contact and telemetry enabled
Bluetooth Connectivity	Yes
User Profiles	4
Maximum User Weight	300 lbs
