Nautilus F3AT - HARDWARE AND TOOLS; HARDWARE CARD; TOOLS NOT PROVIDED

5
Nautilus® Commercial Free Weights Adjustable Tower Assembly Manual
REF # DESCRIPTION QTY
1 CLIP, CARABINEER 2
2 PLASTIC PLUG 2
3 SCW-BHCS 0500x2 G5-BLKZ 3
4 SCW-BHCS 0500x2.75 G5-BLKZ 3
5 SCW, BHSC 0500x3 G5-BLKZ 4
6 SCW, BHSC 0500x3.25 G5-BLKZ 5
7 SCW, BHSC 0500x6.5 G5-BLKZ 2
8 SCW, BHSC 0500x6.75 G5-BLKZ 6
9 WSH-FLAT 0500 REGULAR BLKZ 40
10 NUT-NL 0500 G-5 BLKZ 21
11 SCREW, BHSC 1/4x.75, TH CUTTING 1
12 SCW-SHCS 0250x1.75 G5-BLKZ
1
13 WRENCH, ALLEN 5/32 1
14 WRENCH, ALLEN 3/16 1
15 WRENCH, ALLEN 7/32 BLK 1
16 WRENCH, ALLEN 5/16 BLK 1
HARDWARE CARD
HARDWARE NOT TO SCALE
TOOLS NOT PROVIDED
3/4” Wrench or Adjustable Wrench
9/16” Wrench or Adjustable Wrench
7/16” Wrench or Adjustable Wrench
5/16” Wrench or Adjustable Wrench
6
2
1
8
4
3 11
16
15
12
10
5
7
14
9
13
HARDWARE AND TOOLS
