Nautilus ONE Service Manual

Nautilus ONE™ Tower Shroud Installation
(cont.)
Attach the Top Cover
6-1 Lower the top cover onto side shrouds making sure that
the tops edges of both side shrouds fit securely into
the slots on each side of the top cover (Figure 5and 6).
Note: Push inward on the top edge of the length of both side
shrouds to assure the top cover is securely attached.
If you can push the shroud inward, it is not in the slot
and needs to be installed again.
6-2 Install the two mounting screws on the rear of the top
(Figure 7).
Note: Overtightening the shield screws may cause the top
shield to crack.
Figure 6
Figure 7
Figure 5
Service Manual
8

Nautilus ONE Specifications

General

Target Muscles	Full Body
Usage	Home
Frame Material	Steel
Type	Elliptical
User Interface	LCD
Display	LCD
Heart Rate Monitoring	Yes
Resistance System	Eddy Current Brake (ECB)
