Nautilus ONE Service Manual

Table of Contents
Safety Warnings ...........................................................................................................................1
Exploded Views ...........................................................................................................................2
Service Procedures ......................................................................................................................5
Tower Shroud Removal ..............................................................................................5
Tower Shroud Installation ..........................................................................................7
Weight Drive Installation/Removal ............................................................................9
Screw Belt Adjustment ............................................................................................. 11
Bottom Loading Gas Spring Replacement ..............................................................12
Knob Removal ........................................................................................................... 18
Contact Information .................................................................................................................. 19
Required Tools
1) 9/16" Socket Wrench
2) 3/4" Socket Wrench
3) Torque Wrench
4) 9/16" Wrench
5) Adjustable Wrench
6) 5/32" Hex Wrench
7) 5/16" Hex Wrench
8) 7/32" Hex Wrench
9) 1/4" Hex Wrench

Nautilus ONE Specifications

General

Target Muscles	Full Body
Usage	Home
Frame Material	Steel
Type	Elliptical
User Interface	LCD
Display	LCD
Heart Rate Monitoring	Yes
Resistance System	Eddy Current Brake (ECB)
