Exploded Views
Weight Selection
Knob Assembly
Weight Selection
Front Bezel
Number Wheel
Number Wheel
Base
Add-on Weight
Lever
Weight Selection
Backing Plate
BH Bolt 1/4"-20
UNC X
Wheel Adjustment
Screw #8 x 1/2"
#8 Steel Washer
Plastic Washer 1.0 ID
x 1.5 OD x 0.0625 L
IGUS Bushing 1"
ID x 1/2"
IGUS Bushing 1"
ID x 1/2"
Steel Washer
1.0" ID
WT-SYS-250-5
Weight Selection Assembly
Service Manual
