Nautilus U618 Assembly Manual

9
ASSEMBLY
1. Attach Stabilizers to Main Frame
Note: Hardware() is preinstalled on the stabilizers and not on Hardware Card. Make sure transport wheels on
the front stabilizer point forward.
2. Install Console Mast and Mast Boot on Main Assembly
NOTICE: Make sure the Console Cable connector (a) does not fall into the Console Mast. Align the clips on the
cable connectors and make sure the connectors lock. Do not crimp Console Cable.
X2
6 mm
*
*
*
X2
6 mm
*
*
*
2
3
1
a
4
5
A
6 mm
C
B
X4

Nautilus U618 Specifications

General

Bluetooth Connectivity	Yes
User Profiles	4
Resistance Type	Magnetic
Transport Wheels	Yes
Display	LCD
Heart Rate Monitoring	Contact
Seat	Adjustable
Flywheel Weight	18 lbs
Maximum User Weight	150 kg
