Nautilus U624 User Manual

9
3. Install Handlebars on Console Mast
NOTICE: Do not crimp the cables. Put the Handlebar (7) in the bracket (5a), adjust the Handlebar to the desired
angle, and install the T-handle (D) through the holes. Use the pull cable in the Handlebar Mount to route
the HR cable (7a) through the slot (5b) under the Handlebar Mount to the top of the mast. Fully tighten the
T-handle to keep the Handlebar in position. Push the cover (6) into position on the Handlebar Mount.
5a
D
E
B
7
D
E
B
7a
7
6
D
7a
7
5b
5a

Nautilus U624 Specifications

General

Brand	Nautilus
Model	U624
Category	Exercise Bike
Language	English
