Navien NPE-150S2 User Manual

12 About the Water Heater
2.6 Dimensions
The following diagrams show the dimensions of the water heater and the table lists the supply.
27.4 in. (695 mm)
28.8 in. (731 mm)
Supply Connections
Description Diameter
A Air Intake 2 in.
B Exhaust Gas Vent 2 in.
C Hot Water Outlet
3
/
4
in.
D Gas Inlet
3
/
4
in.
E Recirculation Inlet
3
/
4
in.
F Condensate Outlet
1
/
2
in.
G Cold Water Inlet
3
/
4
in.
Overhead View
3 in. (77 mm)
6.7 in. (170 mm)
4.5 in. (115 mm)
0.4 in. (10 mm)
1.5 in. (38 mm) 14.3 in. (364 mm)
2.6 in. (67 mm)
A
B
Supply Connections
13.2 in. (336 mm)
2.3 in. (60 mm) 3.0 in. (77 mm) 8.3 in. (212 mm)
17.3 in. (440 mm)
2.4 in. (61 mm)
2.4 in. (61 mm)
C
D E F G
6.5 in. (166 mm)
[NPE-180A2/ 210A2/ 240A2]

Navien NPE-150S2 Specifications

General

Brand	Navien
Model	NPE-150S2
Category	Water Heater
Language	English
