9About the Water Heater
2.5 Components
The following diagram shows the key components of the water heater. Component assembly diagrams and
particular parts lists are included in the Appendixes.
Intake Air/Exhaust Duct
Condensate Drain
STS Heat Exchanger
NaviTech
TM
Burner
Ignitor&Flame Rod
Front Panel
PCB
Water Inlet Filter
Gas Inlet Fitting
Fan Motor
Ignition Transformer
APS (Air Pressure Sensor)
DHW Supply Fitting
Cold Water Inlet Adapter
[NPN-160U/180U/199U]
