Navistar MaxxForce 10 Diagnostic Manual

DIAGNOSTICMANUAL
Step
ActionDecision
13
Verifyexhaustgastemperaturesarewithinspecication.
1.UsingElectronicServiceTool(EST)with
ServiceMaxx™software,gotoSessions>Performance
andselecttherecordsnapshoticonfromthetoolbar.
2.GotoTests>KOERAftertreatmentT ests>Onboard
FilterCleanlinessTest.
WhenOBFCTiscomplete,stoprecording.Usetheplayback
featureandgraphthefollowingsignalvaluesfromOBFCT :
SignalValues:
•DieselOxidationCatalystInletT emperature(DOCIT)
•DieselParticulateFilterInletTemperature(DPFIT)
•DieselParticulateFilterOutletT emperature(DPFOT)
•DPFSootLoad
ComparesnapshottoGraph5,6,and7page57.
Whichgraphdoessnapshotmostcloselymatch?
Graph5:Diagnosticscomplete
Graph6:Gotostep14
Graph7:Gotostep16
40
