Navman Qube 300 Installation Manual

Qube 300 | Installation Manual
10
2
White
+3.8V DC
Reference for Analogue Input
3
Yellow
Multi I/O-1
Digital Input OR Digital Output OR Analogue Input 1
(Also Wake from Sleep)
4
Green
Multi I/O-2
Digital Input OR Digital Output OR Analogue Input 2
5
Light Blue/Black
RXD-2
RS232 Serial Port 2 Data Input
6
Light Blue
TXD-2
RS232 Serial Port 2 Data Output
7
Orange
1 W+
Temperature Probe Power Supply
8
Orange/White
1 WD
Temperature Probe Data
10-Way Expansion Connector:
Pin
Wire Colour
Function
Description
1
Black
GND
Ground Output
2
Brown
TXD-3
RS232 Serial Port 3 Data Output
3
Brown/White
RXD-3
RS232 Serial Port 3 Data Input
4
Black
GND
Ground Output
5
Purple
DI-4
Digital Input 4 (Active High/Low) (Wake from Sleep and
RPM Count)
6
Blue
DI-3
Digital Input 3 (Active High/Low) (Wake from Sleep)
7
Blue/White
DI-2
Digital Input 2 (Active High/Low) (Wake from Sleep)
8
Green/White
DI-1
Digital Input 1 (Active High/Low) (Wake from Sleep)
9
Light Green
DO-1
Digital Output 1 (Active Low only)
10
Grey
DO-2
Digital Output 2 (Active Low only)
Wake from sleep configuration
Wake from sleep can be triggered on MIO-1 Active HIGH ONLY and on DI-1 thru DI-4 in either an Active
HIGH or Active LOW configuration.
When the event is triggered the Qube300 will fully boot up, send any sensor events triggered and after 5
mins return to sleep mode.
Note: If a senor input line is configured for read with ignition on only, Qube300 will boot up but not send
sensor events.
