4 Installation & Wiring
4.1 Before Starting
Check that all cables are long enough to reach between the chosen Qube 300 location, the antenna location,
and the ignition loom (or fuse box).
Test the proposed antenna location to check whether it will give the best performance.
Check that the SIM Card has been installed into the Qube 300 (see Section 4.3 for the location).
4.2 3-Wire Basic Tracking & Antenna Connections
The 3-Wire Power cable, a GPS Antenna, and a Cellular Antenna, are the minimal requirements for tracking
only.
Ensure that all cables are:
 tidy and secure, and do not present a hazard to the users of the vehicle/asset
 protected from chaffing on sharp edges
 connected to manufacturer’s approved points
 located where they will not be damaged
Pin
3-Wire Colour
Function
Description
1
Black
GND
Vehicle Ground/chassis connection.
2
Red
+12/24V DC
Main power connection (main vehicle supply). This
connection must be fused (3 Amp Slow Blow).
4
Pink
Ignition Detect
Positive input from vehicle when the key is in the IGNITION
position (not the Accessory position).
This signal must remain ON during engine cranking / start-
up. This connection must be fused (3 Amp Slow Blow).
CAUTION
Ensure that any connection to the vehicle wiring system does not interfere with the operation of the
vehicle or with any of the vehicle’s safety systems. If in doubt, consult the vehicle manufacturer.
Use insulation tape to insulate any bare wires that are not connected.
Wiring the unit incorrectly or leaving any bare wires exposed may result in electrical damage to the Qube
300 or the vehicle’s electrical system.
