NBN connection box - Alternative Equipment Setup with Battery Backup; Diagram of Alternative Setup

7
© 2015 nbn co ltd | ABN 86 136 533 741
*
Also known as a Premises Connection Device.
With nbn
™
connection box (no cover), Fibre Wall Outlet
and Power Supply with Battery Backup
SYSTEM
STATUS
BATTERY
POWER
REPLACE
BATTERY
ALARM
SILENCE
ALARM
SILENCE
BATTERY
EMERGENCY
USE
NTD
Property
of nbn™
Do not remove
nbn
™
utility box
*
Inside your
premises
Outside your
premises
nbn
™
connection box
(no cover)
Power Supply with
Battery Backup
Fibre wall
outlet
