32
Example bottle holder assembly optional
When mounting the bottle holder, the APPCON 3000 is mounted
laterally below the water bottle using an aluminium adapter (opti-
onal).
This type of mounting is only recommended if the rear and front
wheels are tted with mudguards.
Dynamo cable installation
1. you do not use the dynamo to power your lighting system
2. you use a Shimano Dynamo and feed your light with it
3. you use a SON dynamo and feed your light with it
1. you do not use the dynamo to power your lighting system
That‘s easy. In the case of Shimano, simply plug the pre-assembled
Dynamo plug into the Dynamo hub connector. Look at the plug, it
can only be pushed on from one side. In case of a SON hub you
have to remove the two at plugs from the prefabricated Dynamo
plug and then put them back on the SON. If the at plugs are loose,
you may have to squeeze the at plugs with pliers to make a tight
connection to the SON Dynamo. The polarity is not relevant for the
SON Dynamo. So just plug it in.
