NC SW6 - Page 22

22
AXLE
Service Points & Fluid Levels
Operation 10
Hr
50
Hr
100
Hr
1000
Hr
2000
Hr
Hubs Check for Leaks ● ● ● ●
Axle Oil Level (incl. Hubs when applicable) Check ● ● ● ●
Axle Oil Change ● ● ●
Tightness of Mounting bolts (Torque to 970Nm / 715lbf ft) ● ● ● ● ●
Tightness of Wheel Rim Nuts (Torque to 680Nm / 500lbf ft) ● ● ● ● ●
Service Schedules
GEARBOX
Pre-start Cold Checks
Operation 10
Hr
50
Hr
100
Hr
500
Hr
1000
Hr
Transmission oil level Check ● ● ● ● ●
Transmission Oil Change ●
Transmission Filter Change ● ● ●
Transmission Strainer Clean ●
Drive Shafts Security ● ●
Functional Test
Forward & Reverse Gear Change operation Check ● ● ●
Transmission Main Line Pressure Check ● ●
Clutch Disconnect Check ● ● ●
Neutral Start Operation Check ● ● ●
Clutch Back Pressures Check ● ● ●
BRAKES
Parking Brake Operation Check ● ● ● ● ●
Note: First 10 Hr Service only.
Note: First 100 Hr Service only.
Note: Indicates jobs which should only be undertaken by a specialist.
TRANSFER BOX
Service Points & Fluid Levels
Operation 10
Hr
50
Hr
100
Hr
1000
Hr
2000
Hr
Oil Leaks Check ●
Oil Level Check ●
Oil Change ●
