NCR 7772 Series - Hospitality I;O Ports

Hardware Installation 2-17
Hospitality I/O
The following are the default I/O ports for the NCR CX7 All-in-One POS (7772) with a
Hospitality I/OBase.
Callout Port Name
1
RJ45 Serial
2
Dual USB 3.0
3
USB12V
4
USB24V
5
24VPower In
6
LED
7
USB-C
8
LANOut
9
LAN In
10 DisplayPort
11 Cash Drawer
12 RJ12 Serial
