Electromagnetic Compatibility Tables | 35
7.2 Guidance and Manufacturer's Declaration - Electromagnetic Interference Immunity
This product is intended for use in the electromagnetic environment specified below. The customer or the
user of the product should assure that it is used in such an environment.
Immunity Test Immunity Test
Electrostatic discharge (ESD) IEC61000-4-2
±2, ±4, ±6, ±8 kV contract discharge
±2, ±4, ±6, ±8, ±15 kV air discharge
Radiated RF field IEC61000-4-3
3 V/m
80MHz - 2.7GHz
80% AM 1 kHz
Proximity fields from wireless transmitters
IEC61000-4-3
80MHz to 2.7GHz. 3V/m
Spot Tests: 385MHz. at 27 V/m;
(710, 745, 780, 5240, 5500, 5785)MHz at 9V/m;
(450, 810, 870,930, 1720, 1845, 1970, 2450)MHz at
28V/m
Electrical fast transient / burst IEC61000-4-4
±2 kV, AC mains
±1 kV, I/O ports
100 kHz PRR
Surge IEC61000-4-5
AC mains, Line to Ground
AC mains, Line to Line
±0.5, ±1, ±2 kV
±0.5, ±1 kV
Conducted RF IEC61000-4-6
3 V (0.15MHz – 80 MHz)
6 V ISM Bands
80% AM 1 kHz
Power frequency (50/60 Hz) magnetic field
IEC61000-4-8
30 A/m - 50 or 60 Hz
Voltage dips, short interruptions and voltage vari-
ations on power supply input lines IEC61000-4-11
100%dip, 0.5 periods, 0°, 45°, 90°, 135°,
180°, 225°, 270°, 315°
100%dip, 1 period
30% dip, 25/30 periods (50/60 Hz)
Interrupt 100%drop, 5s
NOTE!
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV
broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be con-
sidered. If the measured field strength in the location in which the product is used exceeds
the applicable RF compliance level above, the product should be observed to verify normal
operation. If abnormal performance is observed, additional measures may be necessary,
such as re-orienting or relocating the product.
