TROUBLESHOOTING
REMOVAL AND DISPOSAL
Problem Possible cause Solution
BC50 controller is not
working (graphical UI
remains black)
• No or incorrect power supply.
• Controller defect
• Ensure the specified voltages are
correct for the current setup.
• Ensure the connections from the
power supply to the BC50 controller
are correctly inserted, and if neces-
sary, correct them.
• Replace controller
Motor is not running • Motor not properly connected.
• Motor run is turned o in the
settings.
• Motor is stalled/blocked.
• Motor is broken
• Check motor cable.
• Change settings or I/O input signals.
• Check UI and remove blockage.
• Replace motor.
Motor speed does not
correspond to actual
speed
• Motor type or diameter is set
incorrectly
• Change motor type and diameter to
the correct setting
Removal
Beware of the risk of injuries while removing the BC50 controller from the
conveyor system. Only authorized and qualified personnel is allowed to
perform these kinds of tasks. Make sure that the power is switched o and
cannot be accidentally switched on again during removal. When removing
the controller from the conveyor system, make sure the following tasks are
being executed in this specific order:
• Cut all power from the system or, if applicable, the specific segment.
• If necessary, label the cables in order to ensure they are put back in the
right place.
• Disconnect all the cables from the BC50 controller.
• Remove the mounting screws that secure the controller to the
conveyor system.
• Gently remove the controller. Make sure not to drop or bump the controller,
this might result in irreversible damage.
• Make sure any loose cables are o the floor and cannot be damaged
by accident.
Disposal
The disposal of the BC50 controller must be compliant to industry-specific
national or local provisions. The responsibility for correct disposal of the
BC50 controller and the accompanying packaging and accessories lies
completely with the industrial operator which should consider the proper
regulations surrounding disposal of electronic devices.
ACCESSOIRIES
Cable accessories
Power cable 24V
5000mm, one-sided connector, order code: 901-CABP24-1-5000
COM cable
5000mm, one-sided connector, order code: 901-CABCOM-1-5000
E-roller extension cable
Standard lengths
1500mm, two-sided connector, male/female, order code: 901-CABMOT-1500
3000mm, two-sided connector, male/female, order code: 901-CABMOT-3000
M8-5pin Adapter cable
Standard lengths
310mm, two-sided connector, M8 male/24V PWR&COM, order code:
901-ADP-B-SC (M8 Screw-in)
310mm, two-sided connector, M8 male/24V PWR&COM, order code:
901-ADP-B-SN (M8 Snap-in)
*Custom lengths on request. L stands for required cable length.
NOTES
