NEC 424 - Cover Inside; Rear Face

ENG-8
Cover Inside
Adjustment Dial A
Adjustment Dial B
CAUTION
• Whenthetouchmoduleismountedonascreenorawhiteboardbymagnets,holdthe
touch module and then remove the cover. Otherwise, the touch module may fall down and
may cause of injury.
Rear Face
Laser diffusion port
Magnet
Caution:
•Donottouchthelaserdiffusionports.Itmaycauseofmalfunction.
Note:
The security slot supports the MicroSaver® Security system.
