4 MOUNTING THE AP400 AGAINST A
WALL/CEILING
PROCEDURE: “Procedure for mounting the AP400 to the wall”.
Actions
1. Remove the mounting plate from the AP400 cabinet.
Figure 12. How to take the mounting plate off.
Push clip up, to
take mounting
plate off.
