Specifications
DSX Component Guide Specifications and Parts ◆ 31
Specifications
and Parts
Mechanical Specifications
Equipment Width Depth Height Weight
DSX-40 Cabinet
DSX-80 Cabinet:
DSX-160 Cabinet
13 3/16”
10 3/4”
19 1/2”
2 3/4”
5 7/8”
5 7/8”
10 1/2”
13 11/16”
13 11/16”
3 lbs 9.5 oz
4 lbs 5 oz
6 lbs 12 oz
Display Keyset: 7 5/8” 9 1/2” 4 3/4” 2 lb. 5.7 oz.
Super Display Keyset: 7 5/8” 9 1/2” 4 3/4” 2 lb. 6.5 oz.
60-Button DSS Console 5 5/8” 9 1/2” 4 3/4” 1 lb. 3.4 oz.
DSX Analog Door Box 3 3/4” 1” 5” 6.2 oz
DSX-40 Built-In Analog Door Box Relay Contacts
Contact Configuration: Normally open
Maximum Load: 0.5A @ 120 VAC
1A @ 24 VDC
Maximum Initial Contact Resistance: 100 mOhms
2PGDAD Module Analog Door Box Relay Contacts
Relay Contacts
Configuration: Normally open
Maximum Contact Ratings: 250 mA @ 120 VAC
500 mA @ 24 VDC
BGM/MOH Music Source Inputs
Music inputs are located on the CPU Card.
Input Impedance: 10K Ohms
Input Level: +18 dBr (+ 2 dBr) @ 1.0 Khz
USB and Ethernet Specifications
DSX-40 USB and ethernet connectors are located on the cabinet.
DSX-80 USB and ethernet connectors are located on the CPU Card.
USB: USB 2.0 full speed (12 Mbits/sec)
Ethernet Auto Sensing
