Getting started
Getting started
Installing the battery pack
1. Place the handset face down on a flat surface.
2. Slide the lock at the bottom of the battery
compartment cover upwards and at the same time lift
the cover away from the handset.
3. Remove the battery compartment cover.
4. Push the battery pack into the casing.
5. Replace the battery cover.
Installing the charger
1. Place the charger on a flat surface.
2. Connect the USB-C connector of the USB cable to (the
back of) the charger.
3. Connect the type A USB connector to the USB AC/DC
Adapter.
4. Connect the adapter to an electrical outlet.
5. Place the handset on the charger as shown in Figure 1.
Figure 1: G277/G577/G577h in Desktop Charger
