NEC ITY-6D - Installing the Wall Mount Unit

Figure 18: Sliding the Hanger Hook into Position
Installing the IP4WW-Wall Mount Unit
1. From the back of the terminal, move the handset cable to the
cable groove shown (refer to Figure 19: Relocating the Handset
Cable).
Note: Before moving the leg to the folded position, the handset cable must be
installed in the cable groove shown to prevent damage to cable.
Figure 19: Relocating the Handset Cable
2. Move the leg to the folded position.
3. Attach the IP4WW-Wall Mount Unit to the terminal (refer to Figure
20: Installing the IP4WW-Wall Mount Unit).
36
