6
1. Introduction
Monaural Speaker (2W)
AC Input
Connect the supplied power cable's
three-pin plug here, and plug the other
end into an active wall outlet.
(See page 26)
Main Power Switch
When you plug the supplied power cable into an active wall
outlet and turn on the Main Power switch, the POWER
indicator turns orange and the projector is in standby mode.
(See page 28)
Remote Sensor
(See page 12)
PC Card Slot
Rear Foot
Ventilation (outlet)
Lamp cover screw
Rear Foot
Rotate to make the projector level.
(See page 31)
PC Card Eject Button
Lamp cover
(See page 119)
