1. Introduction
Terminals Features
1246
14
13
7
98
1211 10 35
1. COMPUTERIN/ComponentInputTerminal(Mini
D-Sub15Pin)
(→page122, 124, 126)
2. COMPUTERAUDIOINMiniJack(StereoMini)
(→page122, 124, 126)
3. HDMI1INTerminal(TypeA)
(→page122, 127)
4. HDMI2INTerminal(TypeA)
(→page122, 127)
5. USB-BPort(TypeB)
(→page42, 43)
6. MONITOROUT(COMP.)Terminal(MiniD-Sub15
Pin)
(→page124)
7. AUDIOOUTMiniJack(StereoMini)
(→page124)
8. VIDEOINTerminal(RCA)
(→page125)
9. VIDEOAUDIOINL/MONO,R(RCA)
(→page125)
10.MICInputJack(MonauralMini)
(→page70)
11.LANPort(RJ-45)
(→page128)
12.USB-APort(TypeA)
(→page75)
13.3DSYNC(MiniDIN3Pin)
(→page66)
14.PCCONTROL[PCCONTROL]Terminal(D-Sub9
Pin)
(→page150)
 UsethisporttoconnectaPCorcontrolsystem.This
enablesyoutocontroltheprojectorusingserialcommu-
nicationprotocol.Ifyouarewritingyourownprogram,
typicalPCcontrolcodesareonpage150.
