2. Projecting an Image (Basic Operation)

❺ Adjusting the Picture Size and Position

Usetheadjustabletiltfoot,thezoomfunctionorthefocusringtoadjustthepicturesizeandposition.

Inthischapterdrawingsandcablesareomittedforclarity.

Adjustingthethrowangle(theheightofanimage)

[Tiltfoot](→page19)

Adjustingtheleftandrighttiltofanimage

[Rearfoot](→page19)

Finelyadjustingthesizeofanimage

[Zoomfunction](→page20)

Adjustingthefocus

[Focusfunction](→page21)

Adjustingthekeystonecorrection[KEYSTONE]*(→page22)

* AutomaticKeystoneCorrectionfunctionisturnedonatthetimeofshipment.Toperformkeystonecorrectionmanually,see“6.

CorrectingKeystoneDistortionManually”onpage22.
