6. Installation and Connections
[M402W/M362W/M322W]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeis
approximately30"(0.76m)measureddiagonallywhentheprojectorisroughly41inches(1.0m)fromthewallor
screen.Thelargesttheimagecanbeis300"(7.6m)whentheprojectorisabout423inches(10.7m)fromthewall
or screen.
300"
Distance
(Unit: m/inch)
Screen Size
Screen Size (Unit: cm/inch)
200"
150"
120"
100"
80"
10.7/422
"
5.3/210
"
4.2/167
"
3.5/139
"
2.8/111
"
2.1/82
"
1.4/54
"
40"
7.1/280
"
60"
30"
1.0/40
"
646.2(W)�403.9(H) / 254(W)�159(H)
430.8(W)�269.2(H) / 170(W)�106(H)
323.1(W)�201.9(H) / 127(W)�79(H)
258.5(W)�161.5(H) / 102(W)�64(H)
215.4(W)�134.6(H) / 85(W)�53(H)
172.3(W)�107.7(H) / 68(W)�42(H)
129.2(W)�80.8(H) / 51(W)�32(H)
86.2(W)�53.8(H) / 34(W)�21(H)
64.6(W)�40.4(H) / 25(W)�16(H)
Lens center
TIP:
• Thedistancesareindicatedbyintermediatevaluesbetweenteleandwide.Useasaruleofthumb.
• Formoredetailsonthrowdistance,seepage119.
[M332XS]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately60"(1.52m)measureddiagonallywhentheprojectorisroughly27inches(0.68m)fromthewallorscreen.
Thelargesttheimagecanbeis150"(3.8m)whentheprojectorisabout69inches(1.8m)fromthewallorscreen.
150"
120"
Distance
(Unit: m/inch)
Lens center
Screen Size
1.4/55"
1.8/69.2"
1.2/45.5"
0.9/36"
0.7/26.6"
203.2(W)�152.4(H) / 80(W)�60(H)
162.6(W)�121.9(H) / 64(W)�48(H)
121.9(W)�91.4(H) / 48(W)�36(H)
Screen Size (Unit: cm/inch)
304.8(W)�228.6(H) / 120(W)�90(H)
243.8(W)�182.9(H) / 96(W)�72(H)
100"
80"
60"
TIP:
• DigitalZoomcanresultinablurryimageduetotheelectroniczoom.
• Formoredetailsonthrowdistance,seepage119.
