118
6. Installation and Connections
[M352WS/M302WS]
Thefurtheryourprojectorisfromthescreenorwall,thelargertheimage.Theminimumsizetheimagecanbeisap-
proximately60"(1.52m)measureddiagonallywhentheprojectorisroughly22inches(0.6m)fromthewallorscreen.
Thelargesttheimagecanbeis150"(3.8m)whentheprojectorisabout58inches(1.5m)fromthewallorscreen.
150"
120"
Distance
(Unit: m/inch)
Lens center
Screen Size
1.2/46.3"
1.5/58.3"
1/38.3"
0.8/30.3"
0.6/22.2"
Screen Size (Unit: cm/inch)
323.1(W)�201.9(H) / 127(W)�79(H)
258.5(W)�161.5(H) / 102(W)�64(H)
100"
80"
60"
215.4(W)�134.6(H) / 85(W)�53(H)
172.3(W)�107.7(H) / 68(W)�42(H)
129.2(W)�80.8(H) / 51(W)�32(H)
TIP:
• DigitalZoomcanresultinablurryimageduetotheelectroniczoom.
• Formoredetailsonthrowdistance,seepage119.
