NEC MultiSync C431 User Manual

(27/104)
6.3. Operation Code (OP code) Table
Item
OP code
page
OP code Parameter Remarks
INPUT
INPUT 00h 60h 0: No mean
1: VGA(RGB)
5: VIDEO
12(0Ch): YGA(YPbPr)
15(0Fh): DisplayPort
17(11h): HDMI1
18(12h): HDMI2
130(82h): HDMI3
135(87h): MP
OP code page
11h, OP code
06h operation
is same.
PICTURE MODE 02h 1Ah 0: No mean
1: sRGB
3: HIGHBRIGHT
4: STANDARD
5: CINEMA
8: CUSTOM1
9: CUSTOM2
sRGB:
PC mode only
CINEMA:
A/V mode
only
BRIGTNESS
BACKLIGHT 00h 10h 0: dark
|
100(64h): bright
BRIGHTNESS 00h 92h 0: dark
|
100(64h): bright
GAMMA CORRECTION 02h 68h 0: No mean
1: NATIVE
4: 2.2
8: 2.4
COLOR
COLOR 02h 1Fh 0: pale
|
100(64h): deep
COLOR TEMPERATURE 00h 54h 0:2600K
|
74(4Ah):10000K
100K/step
COLOR TEMPERATURE
(CUSTOM)
00h 14h 9: 10000K
11(0Bh): CUSTOM
Select
"CUSTOM"
to
adjust the R
G B gain.
R GAIN 00h 16h 0: Dark
|
255(FFh): Bright
B GAIN 00h 18h 0: Dark
|
255(FFh): Bright
G GAIN 00h 1Ah 0: Dark
|
255(FFh): Bright
COLOR CONTROL 00h RED:
9Bh
YELLOW:
9Ch
GREEN:
9Dh
CYAN:
9Eh
BLUE:
9Fh
MAGENTA:
A0h
0:
|
100(64h):(center)
|
200(C8h):
HUE 00h 90h 0: purplish
|
100(64h): greenish
CONTRAST 00h 12h 0: low
|
100(64h): high

NEC MultiSync C431 Specifications

General

Response time	6.5 ms
Display diagonal	50 \
Display brightness	400 cd/m²
Display technology	LCD
Native aspect ratio	-
Vertical scan range	24 - 85 Hz
Horizontal scan range	31.5 - 91.1 kHz
LED backlighting type	Edge-LED
Display number of colors	1.073 billion colors
Display diagonal (metric)	125.73 cm
Active display area (W x H)	1095 x 616 mm
Supported graphics resolutions	800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768, 1280 x 800, 1280 x 960, 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
USB 2.0 ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Annual energy consumption	110 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	75 W
USB version	2.0
Ethernet LAN	Yes
HDMI ports quantity	3
Compatible memory cards	MicroSD (TransFlash)
Purpose	Universal
Product type	Group video conferencing system
Product color	Black
Number of persons	- person(s)
Operating hours (hours/days)	24/7
International Protection (IP) code	IP5X, IP2X
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Orientation	Horizontal/Vertical
Certification	CE; EMC B; FCC; PSB; TÜV GS; UL/C-UL / CSA; VCCI
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (bottom)	12.4 mm
Panel mounting interface	300 x 300 mm
Audio formats supported	MP3, WAV
Image formats supported	JPG, PNG
Video formats supported	FLV, H.264, MOV, MP4, WMV
Sustainability certificates	RoHS, ENERGY STAR
RMS rated power	20 W
Number of built-in speakers	2
Megapixel	- MP
Image sensor size	- \
Cables included	AC, DisplayPort, HDMI

Weight and Dimensions

Depth	45 mm
Width	1125 mm
Height	645 mm
Weight	16100 g
