10.2 Schedule Write

This command is used in order to write the setting of the Schedule.

1) The controller requests the monitor to write Schedule.

Header Message Check code

Delimiter

SOH-'0'-Monitor ID-

'0'-'A'-'2'-'2'

STX-'C'-'2'-'3'-'E'-PG-EVENT-HOUR-MIN-

INPUT-WEEK-TYPE-PMODE-YEAR-MONTH-DAY-

EXT1-EXT2-EXT3-ETX

BCC CR

Header

SOH (01h): Start of Header

'0' (30h): Reserved

Monitor ID: Specify the Monitor ID of which you want to change a setting.

Ex.) If Monitor ID is '1', specify 'A'.

'0' (30h): Message sender is the controller.

'A' (41h): Message type is "Command".

'2'-'2'(32h, 32h): Message length.

Message

STX (02h): Start of Message

PG: Program No.

'0'-'0'(30h, 30h): Program No.1

'1'-'D'(31h, 44h): Program No.30

EVENT: Schedule event

'0'-'1'(30h, 31h): Power ON

'0'-'2'(30h, 32h): Power OFF

HOUR: Time (hour)

'0'-'0'(30h, 30h): 00

'1'-'7'(31h, 37h): 23 (=17h)

'1'-'8'(31h, 38h): Delete hour

MIN: Time (minute)

'0'-'0'(30h, 30h): 0

'3'-'B'(33h, 42h): 59

'3'-'C'(33h, 43h): Delete minute

INPUT: Input terminal

'0'-'0'(30h,30h): No mean (works on last memory)

'0'-'1'(30h,31h): VGA(RGB)

'0'-'3'(30h,33h): DVI

'0'-'5'(30h,35h): VIDEO

'0'-'C'(30h,43h): VGA(YPbPr)

'0'-'D'(30h,44h): OPTION

'0'-'F'(30h,46h): DisplayPort1

'1'-'0'(31h,30h): DisplayPort2

'1'-'1'(31h,31h): HDMI1

'1'-'2'(31h,32h): HDMI2

'8'-'7'(38h,37h): MP

'8'-'8'(38h,38h): COMPUTE MODULE

WEEK: Week setting

bit 0: MONDAY

bit 1: TUESDAY

bit 2: WEDNESDAY

bit 3: THURSDAY

bit 4: FRIDAY

bit 5: SATURDAY

bit 6: SUNDAY

EX.

'0'-'1'(30h, 31h): MONDAY
