Item
OP code
page
OP code Parameter Remarks
CLOSED CAPTION 10h 84h 0: No mean
1: OFF
2: CC1
3: CC2
4: CC3
5: CC4
6: TT1
7: TT2
8: TT3
9: TT4
RESET
(OSD)
02h CBh 0: No mean
7: Reset
OSD category
Momentary
MULTI DISPLAY
TILE MATRIX
H MONITOR 02h D0h 0: No mean
1
|
10(0Ah)
Number
of H-
division
V MONITOR 02h D1h 0: No mean
1
|
10(0Ah)
Number
of V-
division
POSITION 02h D2h 0: No mean
1
|
100(64h)
TILE COMP 02h D5h 0: No mean
1: NO
2: YES
H SIZE 11h 96h 0: Small
|
200(C8h): Large
V SIZE 11h 97h 0: Small
|
200(C8h): Large
H ADJUSTMENT 11h 98h 0: Left
|
200(C8h): Right
V ADJUSTMENT 11h 99h 0: Down
|
200(C8h): Up
ENABLE 02h D3h 0: No mean
1: NO
2: YES
TILE MATRIX MEM 10h 4Ah 0: No mean
1: COMMON
2: INPUT
MONITOR ID 02h 3Eh 1-100:ID
GROUP ID 10h 7Fh 0: No assignment
1: Group A
2: Group B
3: Group AB
4: Group C
5: Group AC
|
1023(3FFh):Group
ABCDEFGHIJ
Bit0:Group A
Bit1:Group B
Bit2:Group C
Bit3:Group D
Bit4:Group E
Bit5:Group F
Bit6:Group G
Bit7:Group H
Bit8:Group I
Bit9:Group J
RESET
(MULTI DISPLAY)
02h CBh 0: No mean
8: Reset
Multi Display
Category
Momentary
