English-46
You can control multiple monitors by using RS-232C, REMOTE IN or LAN daisy-chain connection.
NOTE: Multiple monitors that are daisy-chained have a limit to the connectable monitors.
When manually specify the ID number or control by the specifi ed ID number, please execute AUTO ID (see page 38)
previously.
Main Monitor Sub Monitors
Connector Connector
IN OUT IN OUT
RS-232C
LAN2 LAN1 LAN2REMOTE IN
LAN1
Connection
LAN Cable
MultiSync
MultiSync
LAN Cable
MultiSync
LAN1
LAN2
LAN1
LAN2
Multiple Monitors Connection
To Next Page
