( CAUTION )
Before making connections, set the standby mode of the projector to "NORMAL" or "Idol mode".
The projector cannot use the control commands in the power-saving condition, but the following model can use
some control commands.
[P350X/P350W/P420X Series]
STANDBY MODE: "POWER-SAVING"
Control Command
Serial
port
Wired
LAN port
Wireless
LAN unit
POWER ON Yes No No
Yes: Supported
No: Not supported
[PA600X/PA550W/PA500U/PA500X Series]
STANDBY MODE: "POWER-SAVING"
Control Command
Serial
port
Wired
LAN port
Wireless
LAN unit
POWER ON Yes No No
[PA600X/PA550W/PA500U/PA500X Series]
STANDBY MODE: "NETWORK STANDBY"
Control Command
Serial
port
Wired
LAN port
Wireless
LAN unit
POWER ON Yes Yes Yes
Yes: Supported
No: Not supported
Baud rate: 38400 bps
(NP600 series, NP610 Series, VT60/VT70/VT80/VT90 series, VT700: 19200bps)
Data length: 8 bits
Parity bit: No parity
Stop bits: 1 bit
Communications mode: Full duplex
The control connector is described below.
[ HT/LT/NP40/VT70/VT80/VT90/WT ]
The PC CONTROL connector is a mini DIN 8-pin connector.
1 To TxD of PC
2
3
4 To GND of PC
5
6
7 To RxD of PC
8
* 2, 3, 5, 6, and 8 are used inside the projector.
