6. Installation and Connections
Lens shifting range
Thisprojectorisequippedwithalensshiftfunction(→page16)foradjustingtheimagepositionusingdials.Lens
shiftingispossiblewithintherangeshownbelow.
NOTE:
• Incaselensshiftedvolumeexceedsthebelowillustratedrange,blurandshademayappeararoundendsofprojectedimage.
Legend:V“Vertical”referstothescreenheightandH“Horizontal”referstothescreenwidth.Thelensshiftrange
isexpressedasaratioofheightandwidth,respectively.
[P554U/P474U/P554W/P474W]
Lensshiftingrange:
Verticaldirection:+55%,−0%
Horizontaldirection:±15%
100%V
55%V
100%H
15%H
15%H
15%H
15%H
Height of projected image
Width of projected image
100%V
55%V
100%H
15%H
15%H
15%H
15%H
Height of projected image
Width of projected image
[P604X/P603X]
Lensshiftingrange:
Verticaldirection:+50%,−0%
Horizontaldirection:±15%
100％V
50%V
100%H
15%H
15%H
15%H
15%H
Height of projected image
Width of projected image
