104
6. Installation and Connections
TIP:
• Withtheprojector’sHDBaseTport,remotecontrolisnotavailablewhentheprojectorisinthestandbymode(serialcommunicationsis
notavailable).(Remotecontrolbecomesavailablewhentheprojector’spowerison).The2(two)methodsbelowcanbeusedtoturnon
theprojector’spowerwhenitisinstandbymode.
1.Theprojectorcanbeoperatedbyconnectingthecomputerandprojectortothenetwork(ontheprojector,usingtheLANportwith
[STANDBYMODE]setto[NETWORKSTANDBY]).
HDBaseT
DC IN
HDBaseT
Computer (for projector control)
Computer (for output)
Example of a transmitter
Switching hub, etc.
VideodevicewithHDMIoutput
2.TheprojectorcanbeoperatedbyRS232Cserialcommunication(Onthisprojector,usethePCCONTROLterminalandtheapplication
software,PCControlUtility,andselect[PCCONTROL]forthe[SERIALPORT])with[STANDBYMODE]setto[NETWORKSTANDBY].
