1. Introduction
Terminal Panel Features
1. COMPUTERIN/ComponentInputTerminal(Mini
D-Sub15Pin)(→page106, 110, 113)
2. COMPUTERAUDIOINMiniJack(StereoMini)
(→
page106, 107, 110)
3. HDMI1/MHLINTerminal(TypeA)
(→
page106, 107, 111, 112)
4. HDMI2INTerminal(TypeA)
(→
page106, 107, 111)
5. USB(PC)Port(TypeB)
(→
page42, 43, 106)
6. MONITOROUT(COMPUTER)Terminal(MiniD-Sub
15Pin)(→page108)
7. AUDIO OUT Mini Jack (Stereo Mini)(→ page
108)
8. VIDEOINTerminal(RCA)(→page109, 113)
9. VIDEO/S-VIDEOAUDIOINL/MONO,R(RCA)
(→
page109)
10.MICInputJack(MonauralMini)
(→page63)
11.LANPort(RJ-45)(→page114)
12.USB(WirelessLAN)Port
(→page115)
13.USBPort(TypeA)(→page66)
14.PCCONTROL[PCCONTROL]Port(D-Sub9Pin)
(→
page136)
 Usethis port to connecta PC or controlsystem.
Thisenablesyoutocontroltheprojectorusingserial
communicationprotocol.Ifyouarewritingyourown
program,typicalPCcontrolcodesareonpage136.
1
2
45
7
6
9
14
8 10
111312 3
