3. Convenient Features

Using on Mac OS

Step 1: Install Image Express Utility Lite for Mac OS on the computer

1. InserttheaccompanyingNECProjectorCD-ROMinyourMacCD-ROMdrive.

 TheCD-ROMiconwillbedisplayedonthedesktop.

2. Double-clicktheCD-ROMicon.

The CD-ROM window will be displayed.

3. Double-clickthe“MacOSX”folder.

4. Double-click“ImageExpressUtilityLite.dmg”.

 The“ImageExpressUtilityLite”windowwillbedisplayed.

5. Draganddropthe“ImageExpressUtilityLite”foldertoyourApplicationsfolderinMacOS.

Step 2: Connect the projector to a LAN

ConnecttheprojectortotheLANbyfollowingtheinstructionsin“ConnectingtoaWiredLAN”(→page114),“Con-

nectingtoaWirelessLAN(Optional:NP05LMseries)”(→page115)and“❿ControllingtheProjectorbyUsingan

HTTPBrowser”(→page45)

Step 3: Start Image Express Utility Lite for Mac OS

1. Open your Applications folder in Mac OS.

2. Double-clickthe“ImageExpressUtilityLite”folder.

3. Double-clickthe“ImageExpressUtilityLite”icon.

 WhenImageExpressUtilityLiteforMacOSstarts,theselectwindowfordestinationwillbedisplayed.

• Atthersttimeofstartup,“ENDUSERLICENSEAGREEMENT” screenwillbedisplayedbeforetheselect

window for destination is displayed.

 Read“ENDUSERLICENSEAGREEMENT”andselect“Iacceptthetermsinthelicenseagreement”,andclick

“OK”.

4. Selectaprojectortobeconnected,andthenclick“Connect”.

 Yourdesktopscreenwillbedisplayedontheprojector.

TIP:

ViewingtheHelpofImageExpressUtilityLiteforMacOS

• Fromthemenubar,click“Help”→“ImageExpressUtilityLiteHelp”whileImageExpressUtilityisrun-

ning.

The Help screen will be displayed



Questions and Answers:

Need help?

Do you have a question about the NEC UM361X and is the answer not in the manual?

NEC UM361X Specifications

General

Native aspect ratio	4:3
Projection distance	0.448 - 0.854 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10, 16:9
Contrast ratio (typical)	6000:1
Screen size compatibility	61.5 - 116 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-10 - 10 °
Focus	Manual
Offset	75 %
Throw ratio	0.36:1
Digital zoom	1.4 x
Zoom capability	Yes
Fixed focal length	4.78 mm
Focal length range	- mm
Aperture range (F-F)	1.8 - 1.8
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	160 W
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
3D	-
Full HD	No
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	720 x 480, 720 x 576, 832 x 624, 1152 x 870, 1280 x 960, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Composite video in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	3
S-Video inputs quantity	0
Maximum digital resolution	1920 x 1200 pixels
Noise level	29 dB
Certification	CE, Gost-R, TÜV GS
Noise level (economic mode)	28 dB
RMS rated power	20 W
Placement	Desktop
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	324 W
Power consumption (standby)	0.5 W
Power consumption (typical)	257 W
Power consumption (economy mode)	214 W
Power consumption (network standby)	3 W
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS
Cables included	VGA
Remote control type	IR
