NEC UM361X User Manual

75
5. Using On-Screen Menu
Menu Item Default Options
SETUP
MENU
COLOR SELECT COLOR COLOR, MONOCHROME
SOURCE DISPLAY ON OFF, ON
ID DISPLAY ON OFF, ON
ECO MESSAGE OFF OFF, ON
DISPLAY TIME AUTO 45 SEC MANUAL, AUTO 5 SEC, AUTO 15 SEC, AUTO 45 SEC
BACKGROUND BLUE BLUE, BLACK, LOGO
FILTER MESSAGE 5000(H) OFF, 100[H], 500[H], 1000[H], 2000[H], 5000[H]
INSTALLATION
ORIENTATION DESKTOP FRONT AUTO, DESKTOP FRONT, CEILING REAR, DESKTOP REAR, CEILING FRONT
CONTROL PANEL LOCK OFF OFF, ON
SECURITY OFF OFF, ON
COMMUNICATION SPEED 38400bps 4800bps, 9600bps, 19200bps, 38400bps
CONTROL ID
CONTROL ID NUMBER 1 1–254
CONTROL ID OFF OFF, ON
TEST PATTERN
MIC SELECT DYNAMIC DYNAMIC, CONDENSOR
MIC GAIN
OPTIONS(1)
AUTO ADJUST NORMAL OFF, NORMAL, FINE
SEAMLESS SWITCHING OFF, ON
FAN MODE AUTO AUTO, HIGH, HIGH ALTITUDE
SIGNAL SELECT
COMPUTER
RGB/
COMPONENT
RGB/COMPONENT, RGB, COMPONENT
VIDEO AUTO AUTO, NTSC3.58, NTSC4.43, PAL, PAL-M, PAL-N, PAL60, SECAM
WXGA MODE
UM361X/UM301X:
OFF
UM351W/UM301W:
ON
OFF, ON
DEINTERLACE ON OFF, ON
HDMI
SETTINGS
HDMI1/
MHL
VIDEO LEVEL AUTO AUTO, NORMAL, ENHANCED
HDMI2 VIDEO LEVEL AUTO AUTO, NORMAL, ENHANCED
AUDIO SELECT
HDMI1/MHL HDMI1/MHL HDMI1/MHL, COMPUTER
HDMI2 HDMI2 HDMI2, COMPUTER
LAN LAN LAN, COMPUTER
USB-B USB-B USB-B, COMPUTER
BEEP ON OFF, ON
OPTIONS(2)
STANDBY MODE NORMAL NORMAL, NETWORK STANDBY
DIRECT POWER ON OFF OFF, ON
AUTO POWER ON OFF OFF, ON
AUTO POWER OFF 1:00 OFF, 0:05, 0:10, 0:20, 0:30, 1:00
DEFAULT SOURCE SELECT LAST LAST, AUTO, COMPUTER, HDMI1/MHL, HDMI2, VIDEO, USB-A, LAN, USB-B
CARBON CONVERT
CURRENCY $, €, JP¥, RMB¥
CURRENCY CONVERT
WIRED LAN
WIRED LAN ENABLE DISABLE, ENABLE
SETTINGS
DHCP: ON
AUTO DNS: ON
DHCP, IPADDRESS, SUBNET MASK, GATEWAY, AUTO DNS, DNS
RECONNECT
WIRELESS LAN
PROFILE DISABLE DISABLE, SIMPLE ACCESS POINT, PROFILE1, PROFILE2
RECONNECT
* Theasterisk(*)indicatesthatthedefaultsettingvariesdependingonthesignal.

NEC UM361X Specifications

General

Native aspect ratio	4:3
Projection distance	0.448 - 0.854 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10, 16:9
Contrast ratio (typical)	6000:1
Screen size compatibility	61.5 - 116 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-10 - 10 °
Focus	Manual
Offset	75 %
Throw ratio	0.36:1
Digital zoom	1.4 x
Zoom capability	Yes
Fixed focal length	4.78 mm
Focal length range	- mm
Aperture range (F-F)	1.8 - 1.8
Lamp power	200 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Lamp power (economic mode)	160 W
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
3D	-
Full HD	No
Analog signal format system	NTSC, NTSC 3.58, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	720 x 480, 720 x 576, 832 x 624, 1152 x 870, 1280 x 960, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1366 x 768, 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Composite video in	1
USB connector type	USB Type-A, USB Type-B
HDMI connector type	Full-size
Serial interface type	RS-232
USB 2.0 ports quantity	3
S-Video inputs quantity	0
Maximum digital resolution	1920 x 1200 pixels
Noise level	29 dB
Certification	CE, Gost-R, TÜV GS
Noise level (economic mode)	28 dB
RMS rated power	20 W
Placement	Desktop
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	324 W
Power consumption (standby)	0.5 W
Power consumption (typical)	257 W
Power consumption (economy mode)	214 W
Power consumption (network standby)	3 W
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS
Cables included	VGA
Remote control type	IR

Weight and Dimensions

Depth	428 mm
Width	378 mm
Height	112 mm
Weight	5600 g
