NEC VT580 - Connecting Your DVD Player with Component Output

16
2. Installation and Connections
Connecting Your DVD Player with Component Output
A component signal will be automatically displayed. If not, from the menu, select [Setup] → [Options] → [Signal
Select] → [Computer 1 ([Computer] on VT58/VT48)], and then place a check mark in the Component radio button.
NOTE: Refer to your DVD player's owner's manual for more information about your DVD player's video output requirements.
AUDIO IN
LR
AUDIO OUT
L R
Component
Y Cb Cr
E
X
I
T
O
N
/
S
T
A
N
D
B
Y
A
U
T
O
A
D
J
.
S
O
U
R
C
E
AUDIO OUT
AUDIO IN
COMPUTER 2 IN
COMPUTER 1 IN
MONITOR OUT(COMP 1)
AUDIO IN
VIDEO IN
PC CONTROL
L
R
S-VIDEO
IN
COMPUTER 1 IN
AUDIO IN
COMPUTER IN
MONITOR OUT
COMPUTER IN
PC CONTROL
R
AUDIO IN
S-VIDEO
IN
VIDEO IN
L
AUDIO IN
DVD player
Audio Equipment
Audio cable (not supplied)
Optional 15-pin - to - RCA (female)
⳯ 3 cable (ADP-CV1)
Component video RCA ⳯ 3
cable (not supplied)
VT58/VT48
VT580/VT480
