NECTA SPA TECHNICAL MANUAL “COLIBRÌ”
Service Manual: Colibrì Edition 02-2002 8 /25
REFERENCE TO RELAY CODE AND ACTUATIONS - ESPRESSO / INSTANT VERSION
Espresso Configuration Instant Configuration
RELAY
CODE
Application RELAY
CODE
Application
K 01
Three-way solenoid valve for
Espresso coffee
K 01
Solenoid valve 3
K 02
Coffee release magnet
K 02
Doser device 3
K 03 Coffee grinder motor K 03 Whipper 2
K 04 Pump K 04 Pump
K 05 Coffee brewer motor K 05 Doser device 4
K 06 Solenoid valve 2 K 06 Solenoid valve 2
K 07 Solenoid valve 1 K 07 Solenoid valve 1
K 08 Whipper 1 K 08 Whipper 1
K 09 Sugar doser device K 09 Sugar doser device
K 10 Doser device 2 K 10 Doser device 2
K 11 Doser device 1 K 11 Doser device 1
K 12 Water inlet solenoid valve K 12 Water inlet solenoid valve
K 13 Cup stacker shift ratiomotor K 13 Cup stacker shift ratiomotor
K 14 Cup release ratiomotor K 14 Cup release ratiomotor
K 15 Stirrer dispensing motor K 15 Stirrer dispensing motor
The control board can be configured for the different machine versions only via software settings.
See Software and Programming chapter
