KORO ESPRESSO
D EEP CLEANING
Removing and sanitising the mixer:
• Detach tube from mixer.
• Rotate the product dispensing nozzle (A) upwards to make
operation easier.
• Rotate the lever (B) anticlockwise.
• Take hold of the mixer assembly (C) firmly, and pull.
1
A
C
B
Removing and sanitising the mixer:
• Separate all the mixer assembly components: product funnel
(A), powder deposit drawer (B), mixing bowl (C).
• Wash, rinse and dry completely.
2
Removing and sanitising the mixer:
• To remove mixer impellers, use a finger to hold the cogged disk
fitted on the mixer shaft below the mixer chamber and unscrew
the impeller.
• Thoroughly wash and clean all of the removed components.
• Reassemble the impeller.
3
Reassemble the mixer:
• Reassemble all the mixer (A) components.
• Rotate the lever ring (B) clockwise to lock the mixer onto the
dispenser.
• Rotate the product dispensing nozzle (C) back down again.
• Connect the tube to the mixing bowl.
4
Cleaning the dispensing spouts:
• Detach the tubes (A) from the dispensing spouts.
• Press pushbutton (B) to release the dispensing spouts carrier
plate (C).
• Detach the dispensing spouts (D) from spout holder (C).
• Thoroughly, wash and clean all the relative components.
5
D
A
C
B
Assembling of the dispensing spouts carrier plate:
• Insert the dispensing spout holder (A) into guide (B) press until it
clicks.
• Reinsert the dispensing spouts onto the spout holder and connect
the tubes onto their spouts.
6
A
B
A
B
C
C
A
B
