Upload procedure:
Click the Browse-button below the preferred update method and select the firmware file (.bin-file). After the file
has been selected, click the Upload-button and confirm the operation. When the update completes, the user is
asked to reboot the device.
Notes: It is recommended, to use the internet explorer to update the firmware. Other browsers may not work or cause
problems with the ANPR firmware.
During the update it is very important to make sure the ANPR is not powered off.
Please do not close the HTTP connection until the download is completed.
Download procedure:
Press the Download-button to save a compressed bin-file containing the ANPR firmware and all its user defined
parameters. This feature is very useful when duplicating the same configuration onto another device or keeping
the file for backup purposes. The bin-file can be directly loaded to an ANPR system, using either of the available
upgrade options.
5.3.5 DEVICE INFO
This page displays information about the ANPR firmware and hardware.
Image Sensor OCR = CCD_1300x1000_BW
Board Serial Number = 583447
Board code = 573
Board revision = 2
FPGA Version = 0
MAC Address = 0x0050C2BE1442
GMT Time & Date = 14.01.21, 13/07/2011, GMT offset: 0min, DST status: OFF
CPU time = 05.15.41
Temperature = Not Available
Flash file system size = 40312 KByte
Boot version = 2.7
TOS version = 4.29.13a
Firmware version = VEGA ACCESS 7.85 NLD-EU May 23 2011 16:25:00
OCR lib version = Tattile Plate Reader Ver.3.05.00
Buffering SD size = 3.8 GB (READY)
Storage SD size = 3.8 GB (READY)
5.3.6 DIGITAL I/O
The ANPR has a number of embedded digital inputs and outputs. Outputs are used for external monitoring
devices or for example control an electronic door lock. Inputs are used as trigger sources. It is possible to check
and modify the status of digital outputs. This function is useful when checking the cabling after installation. See
also chapter 4.4 for details about the digital i/o connections.
Digital input
Green input icon indicates that the input is high (gray is low).
Click on the Refresh-button to update the states of the icons.
Digital output
Red output icon indicates that the output is high (gray is low).
Click on the digital output icon to change its state.
Note: Only digital output 0 is wired on the ANPR.
