ANPR
© Nedap AVI, P.O. Box 103, NL-7140 AC GROENLO Page 27 of 27
B TCP TAG IDENTIFIER OVERVIEW
TAG WEB Description TAG-ID TAG-LEN DATA TYPE
%DATE Date string YYYY-MM-DD. E.g. '2011-07-28' 14000 12 STRING
%TIME Time string HH-MM-SS. E.g. '12-34-56' 14001 16 STRING
%NETBIOSNAME NetBiosName. E.g. 'NEDAP_ANPR1' 14002 32 STRING
%PLATE Number plate, including country. E.g. '46HVR9-NLD' 14003 24 STRING
%PLATE_STRING Number plate, without country. E.g. '46HVR9' 14004 20 STRING
%PLATE_COUNTRY Number plate country. E.g. 'NLD'. See appendix A. 14005 4 STRING
%NREAD Number of times the number plate was read. 14006 4 INT32
%IMAGENAME Image file name. 14007 128 STRING
%IMAGEPATH image file path. 14008 128 STRING
%TRANSIT_ID Transit counter . 14009 4 INT32
%PLATE_MIN_X Upper left X-coordinate of the car plate rectangle. 14010 4 INT32
%PLATE_MIN_Y Upper left Y-coordinate of the car plate rectangle. 14011 4 INT32
%PLATE_MAX_X Lower right X-coordinate of the car plate rectangle. 14012 4 INT32
%PLATE_MAX_Y Lower right Y-coordinate of the car plate rectangle. 14013 4 INT32
%SPEED RFU 14014 4 INT32
%CLASS RFU 14015 4 INT32
%CLASS_STRING RFU 14016 32 STRING
%SN ANPR serial number. 14017 4 INT32
%DIRECTION RFU 14018 12 STRING
%NET_TRIG_ID String received using ethernet trigger. 14019 32 STRING
%IMAGE_BW Camera image in jpeg format. 14020 IMG-DIM BUFFER
%IMAGE_COL RFU 14021 IMG-DIM BUFFER
%OCRSCORE Score of the OCR regarding the number plate reading. 14022 4 INT32
All strings are null-terminated.
The values of IMG-DIM for BUFFER data are not necessarily multiples of 4 bytes, yet the occupied buffer space is
always a multiple of 4 bytes, this in order to keep structure alignment. For example: IMG-DIM is 34231 bytes. But
data buffer sent is larger (so as to keep 4 bytes-alignment) and the result is a 34232 bytes image. When using the
IMG-DIM value to skip to next datum of the message, this should not be overlooked.
