WIM | INSTALLATION GUIDE
Programmer's Guide
17/20
1 to 10 characters.
ww..ww Wiegand output specification. Is exactly
12 hex characters and includes a start-
bit and the complete Wiegand output
format. E.g. parity bits, facility code, id-
number.
Example 1: Request the 1
st
match-list entry. Response contains
license plate 'HK55EVB'.
QLI0000
QLI0000HK55EVB=000006026073
Example 2: Request the 10
th
match-list entry. Empty response.
QLI000A
QLI000A
SNF Set No-Match-Found Entry
Description: Set the no-match-found entry. This entry contains the
Wiegand output specification assigned to every received
license plate that is not found in the match-list.
Syntax: SNFwwwwwwwwwwww
Reply: SNFwwwwwwwwwwww
Where: ww..ww Wiegand output specification used
when license plate not found.
Must be exactly 12 hex characters,
including a start-bit and the complete
Wiegand output format. E.g. parity bits,
facility code, id-number.
Example: Set the no-match-found entry to Wiegand 26-bit facility
code 255, id-number 65553.
SNF00005FFFFFFF
QNF Request No-Match-Found Entry
Description: Request the no-match-found entry.
Syntax: QNF
Reply: QNFwwwwwwwwwwww
Where: ww..ww Wiegand output specification. 12 hex
characters including a start-bit and the
complete Wiegand output format. E.g.
parity bits, facility code, id-number.
CNF Clear No-Match-Found Entry
Description: Clear the no-match-found entry. If the license plate is not
found in the match-list, then no Wiegand output is
generated.
Syntax: CNF
Reply: CNF
