Nedap WIM User Manual

WIM | INSTALLATION GUIDE
Installation
4/20
2 INSTALLATION
2.1 SAFETY PRECAUTIONS
The following safety precautions must be observed during normal use, service and
repair.
• Disconnect the power supply before opening the device.
• The WIM shall only be installed and serviced by qualified and trained
personnel.
• The WIM can be powered from a low power, Class 2 power supply, in
compliance with local regulations.
• To be sure of safety, do not modify or add anything other than mentioned in
this manual or indicated by NEDAP N.V.
2.2 DIMENSIONS
Figure 1: WIM housing dimensions
125 mm [ 4.9 " ]
35 mm [ 1.4 " ]
130 mm [ 5.1 " ]

Nedap WIM Specifications

General

Brand	Nedap
Model	WIM
Category	Control Unit
Language	English
