Nedap WIM User Manual

WIM | INSTALLATION GUIDE
Connections
6/20
The power supply and the DIP-switches are located on the rear panel. See the
picture below.
Figure 3: Rear view
Power input Use the supplied 24VDC power adapter.
Power supplies must be able to supply 12 – 24 VDC / 5 Watt
(positive voltage at center pin).
Switches The switches select the plate conversion mode. See for more
details chapter 5.
Switches
Power input
